TSALA Lever Hoist
TSALA manual lever hoists in catalogue-stated capacities from 0.75 t to 9 t.
- Category
- Manual Hoists
- Subcategory
- Lever Hoists
Product overview
TSALA manual lever hoists in catalogue-stated capacities from 0.75 t to 9 t.
Dimensional views
Use these views with the matching configuration and specification. Drawings are not to scale.
TSALA Lever Hoist — front outline
Original Cooper catalogue outline. Use the matching capacity and chain-fall row in the configuration table; this view is not to scale.
Open full-size image of TSALA Lever Hoist front outline (new tab)
TSALA Lever Hoist — side outline
Original Cooper catalogue outline. Use the matching capacity and chain-fall row in the configuration table; this view is not to scale.
Open full-size image of TSALA Lever Hoist side outline (new tab)Applicable standards
- STD-SANS-1636 — SANS 1636
Configurations
5 available configurations.
| Variant | Capacity | Weight | Capacity / WLL (t) | Chain Falls | Load Chain Diameter (mm) | Weight (kg) | Dimension A (mm) | Dimension B (mm) | Dimension C (mm) | Dimension D (mm) | Dimension E (mm) | Dimension F (mm) | Dimension G (mm) | Dimension Hmin (mm) | Dimension L (mm) | Dimension K (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.75 t | 0.75 t | 7.2 kg | 0.75 t | 1 | 6 mm | 7.2 kg | 136 mm | 148 mm | 325 mm | 290 mm | 30 mm | — | — | — | — | — |
| 1.5 t | 1.5 t | 11.8 kg | 1.5 t | 1 | 8 mm | 11.8 kg | 160 mm | 172 mm | 380 mm | 410 mm | 35 mm | — | — | — | — | — |
| 3 t | 3 t | 23 kg | 3 t | 1 | 10 mm | 23 kg | 180 mm | 200 mm | 480 mm | 410 mm | 40 mm | — | — | — | — | — |
| 6 t | 6 t | 33 kg | 6 t | 2 | 10 mm | 33 kg | 235 mm | 200 mm | 620 mm | 410 mm | 50 mm | — | — | — | — | — |
| 9 t | 9 t | 43 kg | 9 t | 3 | 10 mm | 43 kg | 255 mm | 200 mm | 620 mm | 410 mm | 50 mm | — | — | — | — | — |
Engineering Supplies · Technical data
TSALA Lever Hoist
0.75 t
Read with the product overview, matching product views and compliance information. Confirm the selected configuration with your quotation.
| TSALA Lever Hoist · 0.75 t | |
|---|---|
| Specification | Value |
| Capacity | 0.75 t |
| Weight | 7.2 kg |
| Capacity / WLL | 0.75 t |
| Chain Falls | 1 |
| Load Chain Diameter | 6 mm |
| Weight | 7.2 kg |
| Dimension A | 136 mm |
| Dimension B | 148 mm |
| Dimension C | 325 mm |
| Dimension D | 290 mm |
| Dimension E | 30 mm |
| Dimension F | — |
| Dimension G | — |
| Dimension Hmin | — |
| Dimension L | — |
| Dimension K | — |
Engineering Supplies · Technical data
TSALA Lever Hoist
1.5 t
Read with the product overview, matching product views and compliance information. Confirm the selected configuration with your quotation.
| TSALA Lever Hoist · 1.5 t | |
|---|---|
| Specification | Value |
| Capacity | 1.5 t |
| Weight | 11.8 kg |
| Capacity / WLL | 1.5 t |
| Chain Falls | 1 |
| Load Chain Diameter | 8 mm |
| Weight | 11.8 kg |
| Dimension A | 160 mm |
| Dimension B | 172 mm |
| Dimension C | 380 mm |
| Dimension D | 410 mm |
| Dimension E | 35 mm |
| Dimension F | — |
| Dimension G | — |
| Dimension Hmin | — |
| Dimension L | — |
| Dimension K | — |
Engineering Supplies · Technical data
TSALA Lever Hoist
3 t
Read with the product overview, matching product views and compliance information. Confirm the selected configuration with your quotation.
| TSALA Lever Hoist · 3 t | |
|---|---|
| Specification | Value |
| Capacity | 3 t |
| Weight | 23 kg |
| Capacity / WLL | 3 t |
| Chain Falls | 1 |
| Load Chain Diameter | 10 mm |
| Weight | 23 kg |
| Dimension A | 180 mm |
| Dimension B | 200 mm |
| Dimension C | 480 mm |
| Dimension D | 410 mm |
| Dimension E | 40 mm |
| Dimension F | — |
| Dimension G | — |
| Dimension Hmin | — |
| Dimension L | — |
| Dimension K | — |
Engineering Supplies · Technical data
TSALA Lever Hoist
6 t
Read with the product overview, matching product views and compliance information. Confirm the selected configuration with your quotation.
| TSALA Lever Hoist · 6 t | |
|---|---|
| Specification | Value |
| Capacity | 6 t |
| Weight | 33 kg |
| Capacity / WLL | 6 t |
| Chain Falls | 2 |
| Load Chain Diameter | 10 mm |
| Weight | 33 kg |
| Dimension A | 235 mm |
| Dimension B | 200 mm |
| Dimension C | 620 mm |
| Dimension D | 410 mm |
| Dimension E | 50 mm |
| Dimension F | — |
| Dimension G | — |
| Dimension Hmin | — |
| Dimension L | — |
| Dimension K | — |
Engineering Supplies · Technical data
TSALA Lever Hoist
9 t
Read with the product overview, matching product views and compliance information. Confirm the selected configuration with your quotation.
| TSALA Lever Hoist · 9 t | |
|---|---|
| Specification | Value |
| Capacity | 9 t |
| Weight | 43 kg |
| Capacity / WLL | 9 t |
| Chain Falls | 3 |
| Load Chain Diameter | 10 mm |
| Weight | 43 kg |
| Dimension A | 255 mm |
| Dimension B | 200 mm |
| Dimension C | 620 mm |
| Dimension D | 410 mm |
| Dimension E | 50 mm |
| Dimension F | — |
| Dimension G | — |
| Dimension Hmin | — |
| Dimension L | — |
| Dimension K | — |
